Ride On Electric Pallet Jack

Rated Capacity: 2000/2500/3000kg
Working Temperature: -20℃ ~ 50℃
Standards: CE / ISO Certified
Application: warehouses, logistics centers etc.
Battery: 24V/210, 280, 340Ah
Charger: External
Drive motor: 1.5/2.2 KW AC
Send Inquiry

Product IntroductionTechnical Parameters

Hangzhou Carry Equipment Co., Ltd. is one of the leading manufacturers and suppliers of ride on electric pallet jack in China. If you're going to wholesale durable ride on electric pallet jack made in China, welcome to get pricelist from our factory. All customized products are with high quality and competitive price.





1. EPS – Electric Power Steering System, Operation force light, Save energy, Low noise.



2. Tilter head ergonomically designed for maximum operator comfortable, and control buttons positioned to allow operation with either hand.



3. Double floating springs, patented design of intensifier cylinder, stronger driving force.



4. Electronic lift limitation switch ensure safety and energy-saving.



5. Curtis AC traction controller from USA, stepless speed regulation, automatic protection.



6. Curve automatic deceleration devices, more safe.



7. AC Driving system-Low noise, quiet, without carbon brush and free maintenance.



8. Side-way battery, easy to replace.

3D VIEW



Key Selling Points



High-Strength Conditions

As a rider-on electric vehicle, RPT20/25/30 is suitable for working environment under high-strength conditions. It can provide users with safe, comfortable and reliable logistics solutions.

Innovative Slide Rail Lifting

Innovative slide rail lifting structure reduces wearing and improves power efficiency. It is designed for heavy duty handling and operation in supermarket, logistics center, workshop and warehouses.

Large-Capacity Battery

210/280Ah large-capacity battery meets the needs of continuous work. Side-slidable battery allows customers to easily replace batteries.

Full Steel Cover

The full steel cover well protects important internal parts and reduces the impact on the internal system caused by collisions.



Industry Insights & Market Trends





In recent years, the global electric pallet truck market has maintained steady growth, driven by the rapid development of e-commerce logistics, intelligent warehouse construction and increasing labor costs. More and more enterprises are shifting from manual handling equipment to electric and intelligent models to improve operational efficiency and reduce long-term costs.

The demand for ride on electric pallet jack is growing significantly in medium and large warehouses, logistics hubs and manufacturing bases, as they offer higher efficiency and better operator comfort for heavy-duty and long-distance handling. Key industry trends include wider application of lithium-ion batteries, enhanced safety functions, and higher requirements for waterproof, corrosion-resistant and low-maintenance performance.

As a professional manufacturer and factory supplier, Carryup keeps up with industry trends and continuously optimizes product performance to provide stable and reliable electric pallet handling solutions for global distributors and enterprise buyers.





Our Workshop

Our professional Workshops make sure each equipment high quality.
Mass production provide you very competitive prices.
The input of mass automatic equipment makes our production capacity and quality higher than that of other factories.



Factory Process Of Electric Pallet Truck



Factory Process Of Hand Pallet Truck



More Related Products





FAQ





Q: 1. What is a ride on pallet jack called?

A: A ride on pallet jack is also known as a ride-on electric pallet jack, rider pallet truck or ride-on pallet mover. It is a powered handling vehicle with a riding platform for high-efficiency material transport in warehouses and logistics centers.

Q: 2. Is riding a pallet jack an OSHA violation?

A: Riding a standard non-rider pallet jack is an OSHA violation. However, operating a purpose-built ride-on electric pallet jack with a certified riding platform and safety features is fully compliant with OSHA regulations when used properly.

Q: 3. Are electric pallet jacks worth it?

A: Yes, electric pallet jacks are highly cost-effective for B2B operations. They improve transport efficiency, reduce labor fatigue, lower long-term costs, and deliver strong ROI for warehouses, factories and logistics companies.

Q: 4. What are the common problems with pallet jacks?

A: Common issues include hydraulic leaks, worn wheels or forks, battery or electrical faults, and brake wear. Our ride-on electric pallet jack uses premium components and strict quality control to minimize these failures.

Q: 5. How high can electric pallet jacks lift?

A: Standard ride-on electric pallet jacks have a typical lifting height of 115mm, designed for standard pallet movement on flat ground. For higher lifting needs, electric stackers or reach trucks are recommended.



Hot Tags: ride on electric pallet jack, China ride on electric pallet jack manufacturers, suppliers, factory

Key Technical Parameters





product-304-39 CBD20R-II / CBD25R-II / CBD30R-II (EPS) ELECTRIC PALLET TRUCK

Specification



Product



Electric Pallet Truck

1

Model



CBD20R-II / CBD25R-II / CBD30R-II / CBD35R-II (EPS)

2

Operating type



Stand on

3

Power type



Electric

4

Rated Capacity

kg

2000/2500/3000/3500

5

Load Centre

mm

600

6

Wheels type

mm

PU

7

Wheel base

mm

1454

8

Wheel quantity

mm

1D/4F/1B

9

driving wheel size

mm

¢250×75

10

Balance wheel size

mm

¢115×50

11

Bearing wheel size

mm

¢80×80/¢80×80/¢80×80/¢82×92

Dimensions

12

Min. fork lowered height

mm

85

13

Max. fork lifting height

mm

205

14

Overall fork width

mm

550/600/650/685

15

Fork length

mm

1150/1200

16

Fork width

mm

185

17

Fork thickness

mm

60

18

Overall length

mm

1930(folded)/2345

19

Overall width

mm

820

20

Min. Turning radius

mm

1746/2158

21

Min. Aisle width for pallets 800×1200

mm

2046/2435

22

Min. Aisle width for pallets 1000×120

mm

2480(folded)/2890

Performance

23

Speed

Travel (Laden / unladen)

km/h

5/5

24

Lifting (Laden / unladen)

mm/s

20/25

25

Lowering (Laden / unladen)

mm/s

40/30

26

Max. Gradeability

(Laden / unladen)

%

5/7

27

Service Weight (include battery)

kg

830

Driven

28

Motor

Driven Motor

kw

AC 1.5

29

Lift Motor

kw

DC 1.2

30

Steering motor

kw

DC 0.15

31

Battery

Standard

V/Ah

24/210 (270)

32

Controller

Manufacturer



CURTIS 1230

33

Brake



Electromagnetic / Regenerative
