Electric Pallet Jack

CBD15J
1.5T Walkie Electric Pallet Truck
Capacity: 1.5 tons
Fork width: 550/685
Fork Length: 1150/1220
Charger: External
Drive motor: 1.5/2.2 KW AC
Battery: 24V/70AH
Charger: Build-in
Send Inquiry

Product IntroductionTechnical Parameters

Hangzhou Carry Equipment Co., Ltd. is one of the leading manufacturers and suppliers of electric pallet jack in China. If you're going to wholesale durable electric pallet jack made in China, welcome to get pricelist from our factory. All customized products are with high quality and competitive price.





Primary Equipment for High-Frequency Horizontal Transport



Electric pallet jacks are built for consistent, day-to-day pallet movement. They significantly reduce physical strain and improve operational efficiency.

  • Powered travel and lift
  • Ideal for medium to high-volume operations
  • Increases productivity while lowering labor fatigue
  • Standard equipment in most warehouses





Product Features

◎ Dual tray design allows for easy loading and unloading.
◎ Separately excited motor delivers strong climbing performance.
◎ Stepless speed control ensures smooth and easy operation.
◎ Open battery design enables quick and convenient replacement.
◎ Built-in charger comes as standard for added convenience.
◎ Maintenance-free sealed batteries ensure safe and pollution-free operation.
◎ Compact body design is ideal for working in narrow spaces.
◎ Automatic lifting limit function enhances safety and saves energy.
◎ Equipped with emergency reverse device and emergency brake switch for improved safety.
◎ Low noise and low energy consumption, with daily usage of only about 2kWh.



Why Choose Us



We are a professional manufacturer with independent production lines, stable delivery and competitive factory price.

As an experienced factory, we support OEM/ODM: fork size, load, color, logo and packaging can be customized.

As a reliable supplier, we provide complete export documents, fast after-sales service and long-term supply.

Large quantity orders enjoy better wholesale price and preferential terms.



Factory Process Of Electric Pallet Truck



Factory Process Of Hand Pallet Truck



More Related Products





FAQ





Q1: What is the battery life of an electric pallet truck?

A: Common electric pallet trucks generally use lead-acid batteries or lithium batteries. Lead-acid batteries have a shorter battery life, generally between 4-6 hours, while lithium batteries provide longer working time, usually 8-10 hours or even longer.

Q2: What is an electric pallet truck called?

A: Powered pallet jacks, also known as electric pallet trucks, walkies, single or double pallet jacks, or power jack, are motorized to allow lifting and moving of heavier and stacked pallets. Some contain a platform for the user to stand while moving pallets.

Q3: Do you need training to use a powered pallet truck?

A: To operate an electric pallet truck, employees must have adequate training which involves an assessment and a certification. The training covers practical skills, equipment knowledge, risk awareness and how to use it safely.

Q4: Do you need a driver's license to use an electric pallet jack?

A: OSHA considers electric pallet jacks to be powered industrial trucks (PITs), classifying them as class III, hand and rider forklifts. As a result, operators must be taught and certified to use one safely. Only licensed and trained drivers will be permitted to operate such vehicles and equipment.

Q5: How much does it cost to replace a battery in an electric truck?

A: By comparison, a full EV battery pack can cost anywhere from $5,000 to $20,000+, depending on the battery's make, model and size. This higher cost reflects the larger capacity needed to power the vehicle exclusively with electricity.

Q6: What are two hazards associated with an electric pallet jack?

A: These machines might seem less intimidating than forklifts, but they carry significant risk when misused. Slippery floors, tight corners, or distracted operation can result in crushed limbs or worse. OSHA mandates safety training to reduce these risks.

Q7: What pallets should you not use?

A: You should never use pallets with an MB stamp for any home project, nor should they be burned. It is very unlikely that you would encounter a pallet treated with methyl bromide, but if you do see one, it is best to avoid any contact.



Hot Tags: electric pallet jack, China electric pallet jack manufacturers, suppliers, factory

product-304-39 SPECIFICATION

Specification

1

1.5T WALKIE ELECTRIC PALLET TRUCK CBD15J

2

Model



CBD15J

3

Operating type



Walkie

4

Power type



electric

5

Rated Capacity

kg

1500

6

Load Centre

mm

600

7

Wheels type



PU

8

Wheel base

mm

1280/1235

9

Wheel quantity-Driving / Balance / Bearing



2001/2/4

10

Driving wheel size

mm

¢210×70

11

Balance wheel size

mm

¢84×70 (Double wheel)

12

Bearing wheel size

mm

¢84×101 (Single wheel)

Dimensions

13

Min. fork lowered height

mm

85 (75 as option)

14

Max. fork lifting height

mm

205

15

Max. lifting height

mm

120

16

Outside width between forks

mm

550/685

17

Intside width between forks

mm

390

18

Fork length

mm

1150/1200

19

Fork width

mm

160

20

Fork thickness

mm

73

21

Overall length

mm

1648/1698

22

Overall width

mm

570/685

23

Overall height (With handle)

mm

1213

24

Overall height (Without handle)

mm

634

25

Min. Turning radius

mm

1414/1464

26

Min. Aisle width for pallets 800×1200

mm

1728/1778

27

Min. Aisle width for pallets 1000×120

mm

1764/1814

Performance

28

Speed

Travel (Laden / unladen)

km/h

3.5/4

29

Lifting (Laden / unladen)

mm/s

30/35

30

Lowering (Laden / unladen)

mm/s

35/30

31

Max. Gradeability

(Laden / unladen)

%

5/7

32

Service Weight (include battery)

kg

210

Driven

33

Motor

Driven Motor

kw

DC 0.65

34

Lift Motor

kw

DC 0.8

35

Steering motor

kw

/

36

Battery

Standard

V/Ah

24/75 (Standard) / 85(Options)

37

Weight

kg

50

38

Controller

Manufacturer



CARRY UP (Standard) / CURTIS 1212F (Options)

39

Brake



Electromagnetic / Regenerative



  • Best Fit: Warehouses, distribution centers, busy loading docks, and 3PL facilities.
  • Notice: Handle Self-Installation Required
  • For optimal battery longevity and reliable performance, we recommend charging battery-equipped products monthly (even during storage).
